Rancho RS5000 RS5409 Steering Damper for Jeep Grand Cherokee
Ideal for off-road driving, towing and street applications, Rancho® RS5000® steering stabilizers enhance a vehicle’s performance and minimize on- and off-road driver fatigue by reducing wheel shimmy, bump steer and vibration.
- IMPROVED HANDLING AND PERFORMANCE -- Reduces wheel shimmy, bump steer and vibration which helps minimize on- or off-road driver fatigue
- ACCOMMODATES LARGER TIRES -- Engineered for vehicles with oversized wheels and tires
- ENGINEERED TO LAST -- Features protective boot to safeguard shock rod and oil seal
- HANDLES EXTREME TEMPERATURE CHANGES -- Twin-tube cellular gas design filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
Application Summary:
| Year |
Make/Model |
| 1999-2004 |
Jeep Grand Cherokee |
| Attributes |
| ASIN |
B000CB42EM |
| Body Diameter |
1.875, 47.6 |
| California Proposition 65 |
No |
| Collapsed Length |
12.780 in. |
| Collapsed Length (in.) |
12.780 |
| Compressed Bumper Stop |
No |
| Compressed Length |
12.78, 12.780 |
| Country of Origin (Primary) |
US |
| Dust Shield |
Yes |
| Dust Shield Included |
Yes, Yes |
| Extended Bumper Stop |
No |
| Extended Hydraulic Lockout |
No |
| Extended Length |
20.71, 20.710 in. |
| Extended Length (in.) |
20.710 in. |
| Fully Open Length |
20.710 in. |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8708801600 |
| Hazardous Material Code |
N |
| Hydraulic Lockout |
No, No |
| Includes Bump Stop |
No, No |
| Internal Rebound Bumper |
No |
| Life Cycle Status Code |
Available to Order |
| Lower Mount Code |
LS24 |
| Lower Mount Type |
Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.3/8" Sleeve OAL, Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.3/8" Sleeve OAL |
| Lower Mounting Code |
LS24 |
| Lower Mounting Description |
Loop Bushing & Sleeve Mount - 12MM Sleeve ID X 1.3/8" Sleeve OAL |
| Max Year Covered |
2004 |
| Min Year Covered |
1999 |
| Most Popular Make / Model |
Jeep Grand Cherokee |
| Most Popular Make/Model |
Jeep Grand Cherokee |
| Most Popular Year |
2004 |
| NAFTA Preference Criterion Code |
B |
| Part Description |
Steering Damper, Steering Damper |
| Parts Pack |
P01326 |
| Parts Pack(s) |
P01326 |
| Position |
Front |
| Product Grade |
Premium |
| Reserve Tube Diameter |
1.875 |
| SDR Required Flag |
Y |
| SDS Sheet Number |
01164 |
| Shock Stroke |
7.930 in. |
| Shock Stroke (in.) |
7.930 |
| Total Part VIO |
810654 |
| Travel Length |
7.93 |
| Upper Mount Code |
LS5 |
| Upper Mount Type |
Loop Bushing and Sleeve Mount - 10MM Sleeve ID X 1.7/16" Sleeve OAL, Loop Bushing & Sleeve Mount - 10MM Sleeve ID X 1.7/16" Sleeve OAL |
| Upper Mounting Code |
LS5 |
| Upper Mounting Description |
Loop Bushing & Sleeve Mount - 10MM Sleeve ID X 1.7/16" Sleeve OAL |
| GTIN |
00039703540902 |
